Hydraulic Surface Grinder Machine

Model

H-500

H-600

H-630

H-750

H-750A

H-1000

H-1000A

Working Surface Of Table

500x225

600x250

600x300

750x300

750x400

1000x500

1000x300

Max. Table Travel

525x250

625x260

625x310

760x310

760x400

1010x510

1015x310

Magnet Chuck Suitable

200x450

200x600

300x600

250x750

300x750

1000x500

900x300

Max. Distance Center Of Spindle To Table

390

410

410

410

525

465

465

Vertical Down Feed On Hand Wheel

0.01

Microfeed (Elevation)

0.002/1Div.

Wheel Speed (In RPM)

2800

2800

2800

1400

1400

1400

1400

Wheel Dimension Grinding

200x19x31.75

200x19x31.75

200x19x31.75

250x25x76

300x25x76

350x40x127

300x25x76

Spindle Motor 3 Phase  (In HP)

1

1.5

1.5

2

3

3

3

Table Speed

8-15 m/min.

Auto Cross Feed Increment

0.1-1.0 mm

Cross Feed On Hand Wheel

0.05mm=1 Gra-5.00mm/1 Rev. 1 HP

Hydraulic Pimp Motor (In HP)

1.5

1.5

1.5

2

2

2

2

Hydraulic Tank Capacity (In Ltrs)

45

75

75

75

80

85

80

Floor Area (LxBxH) In Inch

66x47x72

95x58x70

95x60x70

128x68x71

132x80x72

150x78x72

150x78x72
